380V 34KW EVI Monobloc Heat Pumps(SHAW-34EVIM)
- Model
- SHAW-34EVIM
Item specifics
- Net dimensions
- 1495*690*1075(mm)
- Packing dimensions
- 1510*720*1190(mm)
- Power supply
- 380V/3PH/50Hz
- Air flow
- 12000m³/h
- Fan rated power
- 250W*2
- Water pressure drop
- 40Kpa
Review
Description
|
Model |
|
SHAW-34EVIM |
SHAW-40EVIM |
|---|---|---|---|
|
Power supply |
/ |
380V/3PH/50Hz |
380V/3PH/50Hz |
|
Refrigerant |
/ |
R407C |
R407C |
|
Heating capacity 1 |
KW |
34.5 |
41.8 |
|
Heating power input 1 |
KW |
7.86 |
9.55 |
|
COP 1 |
/ |
4.39 |
4.38 |
|
Heating capacity 2 |
KW |
25.4 |
31.5 |
|
Heating power input 2 |
KW |
7.98 |
9.86 |
|
COP 2 |
/ |
3.18 |
3.19 |
|
Heating capacity 3 |
KW |
18.4 |
24.1 |
|
Heating power input 3 |
KW |
7.91 |
9.98 |
|
COP 3 |
/ |
2.33 |
2.41 |
|
Heating capacity 4 |
KW |
17.1 |
21.0 |
|
Heating power input 4 |
KW |
7.89 |
9.78 |
|
COP 4 |
/ |
2.17 |
2.15 |
|
Heating capacity 5 |
KW |
29.20 |
35.80 |
|
Heating power input 5 |
KW |
12.44 |
14.99 |
|
COP 5 |
/ |
2.35 |
2.39 |
|
Max. water temperature |
℃ |
60 |
60 |
|
Rated water temperature |
℃ |
55 |
55 |
|
Water flow |
M³/h |
5.6 |
7.1 |
|
Condenser |
|
tube-in-shell |
tube-in-shell |
|
Water pressure drop |
Kpa |
40 |
42 |
|
Water connections |
Inch |
1.5 |
1.5 |
|
Built-in water flow switch |
|
paddle type |
paddle type |
|
Built-in water pump |
|
NO |
NO |
|
Built-in electric heater |
|
NO |
NO |
|
Built-in auto air vent |
|
NO |
NO |
|
Built-in water expansion vessel |
|
NO |
NO |
|
Compressor |
Brand |
Copeland (EVI) |
Copeland (EVI) |
|
Quantity |
2 |
2 |
|
|
Type of defrosting |
/ |
Reverse circulation |
Reverse circulation |
|
Fan quantity |
|
2 |
2 |
|
Air flow |
m3/h |
12000 |
12000 |
|
Fan rated power |
W |
250*2 |
250*2 |
|
Noise |
dB(A) |
58 |
58 |
|
Net weight |
kg |
265 |
287 |
|
Gross weight |
kg |
280 |
307 |
|
Net dimensions |
mm |
1495*690*1075 |
1495*690*1370 |
|
Packing dimensions |
mm |
1510*720*1190 |
1510*720*1490 |
