20KW Water source heat pumps(SHWW-20Y)
20KW Water source heat pumps(SHWW-20Y)
20KW Water source heat pumps(SHWW-20Y)
20KW Water source heat pumps(SHWW-20Y)
20KW Water source heat pumps(SHWW-20Y)
20KW Water source heat pumps(SHWW-20Y)
Model
SHWW-20Y

Item specifics

Net size
660*530*675(mm)
Power supply
380V/3PH/50Hz
Net weight
99KG
Gross weight
108KG
Circulation pump
Optional
Working mode
Only heating
Noise
42db

Product review

Description

1.   Newdesign, new visible screws outside.

2.   Heatingonly or heating/cooling.

3.   Allcasing panels are easy to remove for maintenance.

4.   Lownoise design, the compressor system is isolated from bottom plate with softrubber mounts.

5.   Noisejacket for compressor.

6.   Pinvalve is easily accessible for maintenance.

7.   Withwater flow switch.

8.   Withdrain pipes for heat exchangers.

9.   Tube-in-shellheat exchangers for heating only units and plate heat exchangers forheating/cooling units.

10. Canwork with room thermostat, master controller, or smart grill signal.

11. Built-inEnergy Class A circulating pump as standard.

12. Weoffer OEM/ODM service.



Model



SHWW-13Y

SHWW-15Y

SHWW-17Y

SHWW-20Y

Specification

Heating capacity

KW

13

15

17

20

Heating power input

KW

2.88

3.33

3.75

4.5

Rated current

A

13.09

15.14

5.70

6.84

COP



4.51

4.50

4.53

4.44

Max. water temp.

60

Rated water temp.

55

Water flow (using side)

m3/h

2.2

2.6

2.9

3.4

Water flow (ground source)



2.5

2.9

3.2

3.8

Net weight

kg

94

95

97

99

Gross weight

kg

103

104

106

108

Noise

db

41

41

42

42

Connection pipe

mm

1"

Power supply



380V/3PH/50Hz

Net dimension

mm

660*530*675

Package dimension

mm

690*560*800

Standard components

Compressor

Brand

Panasonic Scroll

Quantiy

1

Condenser

Plate heat exchanger

Evaporator

Plate heat exchanger

4-way valve

No

Expansion valve

Electronic expansion valve

Circulation pump

Optional

Cabinet

Galvanized white metal sheet

Controller

LCD

High pressure switch

3.0/2.4MPa

Low pressure switch

0.02/0.15MPa

Water flow switch

No

Pressure gauge

Yes (high pressure gauge)

Working mode

Only heating

Refrigerant

R417A
